Product Details
Super G3 modem - fax at 3 seconds* per page
18 page-per-minute, 600dpi laser printer
Large 510-page** memory
Ultra High Quality imaging
500-sheet paper capacity
50-page Automatic Document Feeder
31 one-touch and 167 coded dial keys
210 Sequential Broadcasting/ Delayed Transmissions
Convenient all-in-one cartridge
Fast and cost effective professional laser fax and printer
Productivity
An ideal 'productive' partner, providing 18 pages per minutes laser printing, fast facsimile transmission speed via Super G3 technology and convenience copying all in a single desktop device.
Cost Effective Speed
At Super G3 laser fax speed, documents are transmitted at 3 seconds per page* - twice as fast as ordinary G3 facsimile machines. It also employs state-of-the-art compression protocols to compress image data, especially effective when transmitting halftones.
Receive immediately
There's no time wasted receiving documents either. The FAX-L390 can receive faxes while sending, scanning, or even while producing high-quality laser prints.
Enhanced Image Quality
Benefit from laser quality faxing on plain paper. When transmitting detailed documents, such as diagrams or photos combined with text, Canon's unique Ultra High Quality technology ensures a perfect finish every time.
Powerful Memory Capabilities
For incoming or outgoing faxes, the L390's memory is capable of storing up to 510** pages. Lengthy documents can also be scanned rapidly before transmission and are then sent automatically from memory. If the paper or toner runs out, incoming faxes will be safely stored for printing later.
Stand-alone Laser Printer
This desktop device comes with a built-in Windows print driver can be used as an 18 pages per minute laser printer or copier. Get superior quality output with a high 600 dpi resolution and with Canon's On-Demand fixing technology warm-up time is virtually eliminated for even faster output.
Compact Size
With an upright stance, the L390 has a small foot print taking less space, so it fits comfortably on a desktop.
Time-saving features
With a 500-sheet paper capacity, the cassette needs refilling far less often. While the 50-page Automatic Document Feeder makes light work of faxing large documents in a single operation.
Added Features
Easily employ One-Touch Speed Dialling, Coded Dialling, and Group Dialling to sequentially broadcast to numerous locations. An optional telephone handset adds to convenience.
Convenience Features
Enjoy Print-in-Order output that prints incoming documents face-down, in the correct order, and collated. Work more efficiently, and in less time.
Efficient Design
The L390 uses Canon's single cartridge system. The snap-in, all-in-one cartridge provides quick, convenient maintenance. With standard battery backup, you can safely store incoming documents during a power out-age.
RoHS Compliant
Environmentally friendly, the L390 complies with the European Union's Restriction of Hazardous Substances (RoHS) directive. A first in the BISG range of Canon facsimile devices!
Transmission:
Type:
Plain Paper Laser Facsimile
Applicable Line:
PSTN (Public Switched Telephone Network)
Compatibility:
Super G3
Transmission Speed:
3 seconds per page (A4)
Modem :
33.6Kbps
Error Correction Mode:
Yes
Redial:
Yes (Automatic & Manual)
Speed Dial:
31 one-touch, 167 coded dial
Group Dial:
199 locations
Compression Method:
MMR, MR, MH, JBIG
Memory Functions:
Std Document Memory:
510 pages
Optional Memory:
None
Memory Backup:
Yes (1 hour)
Dual Access:
Yes
Memory Reception:
Yes
Memory Transmission:
Yes
Sequential Broadcast:
Yes, max. 210 destinations
Delayed Transmission:
Yes, max. 210 destinations
Polling:
Yes
Paper Handling:
Printing Method:
Laser beam printing
Print Speed:
Approx. 18 pages per minute
Paper Capacity:
500 sheet cassette
Auto Document Feeder:
50 sheets
Local Copy:
Up to 99 pages
Image Handling:
UHQ Image Processing:
Yes
Image Quality:
Text, Photo, Text & Photo
Halftone:
264 grey scales
UHQ Image Processing:
Yes
Scanning speed:
Up to 24 pages per minute (A4)
Fax Scanning Resolution:
Standard, Fine, Photo, Super Fine, Ultra Fine Photo
Max Document Width:
216mm
Scanning Width:
208mm
Reduction/ Enlargement:
Preset Reduction:
50%, 64%, 78%
Preset Enlargement:
129%, 200%
Print Resolution:
1200dpi (equivalent) x 600 dpi
Auto. Image Reduction:
75 to 100%
Auto. Lighter/Darker Control:
Yes
Resolution:
Transmission:
203 x 98 dpi, 203 x 196 dpi, 203 x 391 dpi, 406 x 391 dpi
Reception:
203 x 98 dpi, 203 x 196 dpi, 203 x 391 dpi, 406 x 391 dpi
Copy Resolution:
300 x 300 dpi
Printing Resolution:
1200 dpi (equivalent) x 600 dpi
System Requirements:
PC Operating System:
Microsoft Windows 98/ME/2000/XP
PC Requirement:
IBM Compatible computer with a Pentium 90 Processor or higher, 16MB RAM, 100MB hard disk space, 256 colour monitor or greater, CD-ROM drive
PC Interface Type (Standard):
USB
General Specifications:
Display:
20 x 2 LCD
FAX-TEL Auto Switch:
Standard (CNG Type)
Auto RX without Ring:
Standard
Answering Machine Connection:
Standard
Remote Reception:
Standard (Dialling Type)
Extension Phone Connection:
Standard
Languages:
English, French, Spanish, Portuguese
Activity Report:
Standard (Up to 20 transactions)
Terminal ID:
Standard
Transmission Header:
Standard
Day Light Saving:
Standard
Power supply:
220-240V (50-60Hz)
Power consumption:
Standby: approx. 4W
During operation: approx 530W (maximum)
Noise Level:
Standby: 30dB
Copying: 50 dB
Energy Star Qualified:
Yes
Dimensions excl. trays (mm):
441 (W) x 466 (D) x 392 (H)
Weight:
Approx. 12.1kgs
Optional:
Handset:
Handset and Cradle Kit
